MediaSession Class Reference

#include <MediaSession.hh>

Inheritance diagram for MediaSession:

Inheritance graph
[legend]
Collaboration diagram for MediaSession:

Collaboration graph
[legend]

Public Member Functions

Boolean hasSubsessions () const
double & playStartTime ()
double & playEndTime ()
char * connectionEndpointName () const
char const * CNAME () const
in_addr const & sourceFilterAddr () const
float & scale ()
char * mediaSessionType () const
char * sessionName () const
char * sessionDescription () const
char const * controlPath () const
Boolean initiateByMediaType (char const *mimeType, MediaSubsession *&resultSubsession, int useSpecialRTPoffset=-1)
UsageEnvironment & envir () const
char const * name () const
virtual Boolean isSource () const
virtual Boolean isSink () const
virtual Boolean isRTCPInstance () const
virtual Boolean isRTSPClient () const
virtual Boolean isRTSPServer () const
virtual Boolean isServerMediaSession () const
virtual Boolean isDarwinInjector () const

Static Public Member Functions

static MediaSession * createNew (UsageEnvironment &env, char const *sdpDescription)
static Boolean lookupByName (UsageEnvironment &env, char const *sourceName, MediaSession *&resultSession)
static Boolean lookupByName (UsageEnvironment &env, char const *mediumName, Medium *&resultMedium)
static void close (UsageEnvironment &env, char const *mediumName)
static void close (Medium *medium)

Protected Member Functions

virtual Boolean isMediaSession () const
 MediaSession (UsageEnvironment &env)
virtual ~MediaSession ()
virtual MediaSubsession * createNewMediaSubsession ()
Boolean initializeWithSDP (char const *sdpDescription)
Boolean parseSDPLine (char const *input, char const *&nextLine)
Boolean parseSDPLine_s (char const *sdpLine)
Boolean parseSDPLine_i (char const *sdpLine)
Boolean parseSDPLine_c (char const *sdpLine)
Boolean parseSDPAttribute_type (char const *sdpLine)
Boolean parseSDPAttribute_control (char const *sdpLine)
Boolean parseSDPAttribute_range (char const *sdpLine)
Boolean parseSDPAttribute_source_filter (char const *sdpLine)
TaskToken & nextTask ()

Static Protected Member Functions

static char * lookupPayloadFormat (unsigned char rtpPayloadType, unsigned &rtpTimestampFrequency, unsigned &numChannels)
static unsigned guessRTPTimestampFrequency (char const *mediumName, char const *codecName)

Protected Attributes

char * fCNAME
MediaSubsession * fSubsessionsHead
MediaSubsession * fSubsessionsTail
char * fConnectionEndpointName
double fMaxPlayStartTime
double fMaxPlayEndTime
in_addr fSourceFilterAddr
float fScale
char * fMediaSessionType
char * fSessionName
char * fSessionDescription
char * fControlPath

Friends

class MediaSubsessionIterator
class MediaLookupTable

Detailed Description

Definition at line 55 of file MediaSession.hh.

Constructor & Destructor Documentation

MediaSession::MediaSession ( UsageEnvironment &  env  )  [protected]

Definition at line 59 of file MediaSession.cpp.

References CNAME(), fCNAME, fSourceFilterAddr, our_random(), and strDup().

Referenced by createNew().

00060   : Medium(env),
00061     fSubsessionsHead(NULL), fSubsessionsTail(NULL),
00062     fConnectionEndpointName(NULL), fMaxPlayStartTime(0.0f), fMaxPlayEndTime(0.0f),
00063     fScale(1.0f), fMediaSessionType(NULL), fSessionName(NULL), fSessionDescription(NULL),
00064     fControlPath(NULL) {
00065   fSourceFilterAddr.s_addr = 0;
00066
00067   // Get our host name, and use this for the RTCP CNAME:
00068   const unsigned maxCNAMElen = 100;
00069   char CNAME[maxCNAMElen+1];
00070 #ifndef CRIS
00071   gethostname((char*)CNAME, maxCNAMElen);
00072 #else
00073   // "gethostname()" isn't defined for this platform
00074   sprintf(CNAME, "unknown host %d", (unsigned)(our_random()*0x7FFFFFFF));
00075 #endif
00076   CNAME[maxCNAMElen] = '\0'; // just in case
00077   fCNAME = strDup(CNAME);
00078 }

MediaSession::~MediaSession (  )  [protected, virtual]

Definition at line 80 of file MediaSession.cpp.

References fCNAME, fConnectionEndpointName, fControlPath, fMediaSessionType, fSessionDescription, fSessionName, and fSubsessionsHead.

00080                             {
00081   delete fSubsessionsHead;
00082   delete[] fCNAME;
00083   delete[] fConnectionEndpointName;
00084   delete[] fMediaSessionType;
00085   delete[] fSessionName;
00086   delete[] fSessionDescription;
00087   delete[] fControlPath;
00088 }

Member Function Documentation

MediaSession * MediaSession::createNew ( UsageEnvironment &  env,
char const *  sdpDescription
) [static]

Definition at line 29 of file MediaSession.cpp.

References env, initializeWithSDP(), MediaSession(), and NULL.

Referenced by continueAfterDESCRIBE(), and DarwinInjector::setDestination().

00030                                                                   {
00031   MediaSession* newSession = new MediaSession(env);
00032   if (newSession != NULL) {
00033     if (!newSession->initializeWithSDP(sdpDescription)) {
00034       delete newSession;
00035       return NULL;
00036     }
00037   }
00038
00039   return newSession;
00040 }

Boolean MediaSession::lookupByName ( UsageEnvironment &  env,
char const *  sourceName,
MediaSession *&  resultSession
) [static]

Definition at line 42 of file MediaSession.cpp.

References env, False, Medium::isMediaSession(), Medium::lookupByName(), NULL, and True.

00044                                                                  {
00045   resultSession = NULL; // unless we succeed
00046
00047   Medium* medium;
00048   if (!Medium::lookupByName(env, instanceName, medium)) return False;
00049
00050   if (!medium->isMediaSession()) {
00051     env.setResultMsg(instanceName, " is not a 'MediaSession' object");
00052     return False;
00053   }
00054
00055   resultSession = (MediaSession*)medium;
00056   return True;
00057 }

Boolean MediaSession::hasSubsessions (  )  const [inline]

Definition at line 63 of file MediaSession.hh.

References fSubsessionsHead, and NULL.

Referenced by continueAfterDESCRIBE().

00063 { return fSubsessionsHead != NULL; }

double& MediaSession::playStartTime (  )  [inline]

Definition at line 64 of file MediaSession.hh.

References fMaxPlayStartTime.

Referenced by continueAfterPLAY(), RTSPClient::handlePLAYResponse(), MediaSubsession::parseSDPAttribute_range(), parseSDPAttribute_range(), MediaSubsession::playStartTime(), and setupNextSubsession().

00064 { return fMaxPlayStartTime; }

double& MediaSession::playEndTime (  )  [inline]

Definition at line 65 of file MediaSession.hh.

References fMaxPlayEndTime.

Referenced by continueAfterPLAY(), RTSPClient::handlePLAYResponse(), MediaSubsession::parseSDPAttribute_range(), parseSDPAttribute_range(), MediaSubsession::playEndTime(), setupNextSubsession(), and setupStreams().

00065 { return fMaxPlayEndTime; }

char* MediaSession::connectionEndpointName (  )  const [inline]

Definition at line 66 of file MediaSession.hh.

References fConnectionEndpointName.

Referenced by MediaSubsession::connectionEndpointAddress(), and parseSDPLine_c().

00066 { return fConnectionEndpointName; }

char const* MediaSession::CNAME (  )  const [inline]

Definition at line 67 of file MediaSession.hh.

References fCNAME.

Referenced by MediaSubsession::initiate(), and MediaSession().

00067 { return fCNAME; }

struct in_addr const& MediaSession::sourceFilterAddr (  )  const [inline, read]

Definition at line 68 of file MediaSession.hh.

References fSourceFilterAddr.

00068 { return fSourceFilterAddr; }

float& MediaSession::scale (  )  [inline]

Definition at line 69 of file MediaSession.hh.

References fScale.

Referenced by RTSPClient::handlePLAYResponse(), and RTSPClient::sendRequest().

00069 { return fScale; }

char* MediaSession::mediaSessionType (  )  const [inline]

Definition at line 70 of file MediaSession.hh.

References fMediaSessionType.

00070 { return fMediaSessionType; }

char* MediaSession::sessionName (  )  const [inline]

Definition at line 71 of file MediaSession.hh.

References fSessionName.

00071 { return fSessionName; }

char* MediaSession::sessionDescription (  )  const [inline]

Definition at line 72 of file MediaSession.hh.

References fSessionDescription.

00072 { return fSessionDescription; }

char const* MediaSession::controlPath (  )  const [inline]

Definition at line 73 of file MediaSession.hh.

References fControlPath.

Referenced by parseSDPAttribute_control(), and RTSPClient::sessionURL().

00073 { return fControlPath; }

Boolean MediaSession::initiateByMediaType ( char const *  mimeType,
MediaSubsession *&  resultSubsession,
int  useSpecialRTPoffset = -1
)

Definition at line 472 of file MediaSession.cpp.

References MediaSubsession::deInitiate(), Medium::envir(), False, MediaSubsession::initiate(), iter, MediaSource::MIMEtype(), MediaSubsessionIterator::next(), NULL, MediaSubsession::readSource(), UsageEnvironment::setResultMsg(), subsession, and True.

00474                                                {
00475   // Look through this session's subsessions for media that match "mimeType"
00476   resultSubsession = NULL;
00477   MediaSubsessionIterator iter(*this);
00478   MediaSubsession* subsession;
00479   while ((subsession = iter.next()) != NULL) {
00480     Boolean wasAlreadyInitiated = subsession->readSource() != NULL;
00481     if (!wasAlreadyInitiated) {
00482       // Try to create a source for this subsession:
00483       if (!subsession->initiate(useSpecialRTPoffset)) return False;
00484     }
00485
00486     // Make sure the source's MIME type is one that we handle:
00487     if (strcmp(subsession->readSource()->MIMEtype(), mimeType) != 0) {
00488       if (!wasAlreadyInitiated) subsession->deInitiate();
00489       continue;
00490     }
00491
00492     resultSubsession = subsession;
00493     break; // use this
00494   }
00495
00496   if (resultSubsession == NULL) {
00497     envir().setResultMsg("Session has no usable media subsession");
00498     return False;
00499   }
00500
00501   return True;
00502 }

Boolean MediaSession::isMediaSession (  )  const [protected, virtual]

Reimplemented from Medium.

Definition at line 90 of file MediaSession.cpp.

References True.

00090                                            {
00091   return True;
00092 }

MediaSubsession * MediaSession::createNewMediaSubsession (  )  [protected, virtual]

Definition at line 94 of file MediaSession.cpp.

Referenced by initializeWithSDP().

00094                                                         {
00095   // default implementation:
00096   return new MediaSubsession(*this);
00097 }

Boolean MediaSession::initializeWithSDP ( char const *  sdpDescription  )  [protected]

Definition at line 99 of file MediaSession.cpp.

References createNewMediaSubsession(), Medium::envir(), False, MediaSubsession::fClientPortNum, MediaSubsession::fCodecName, MediaSubsession::fMediumName, MediaSubsession::fNumChannels, MediaSubsession::fProtocolName, MediaSubsession::fRTPPayloadFormat, MediaSubsession::fRTPTimestampFrequency, MediaSubsession::fSavedSDPLines, fSubsessionsHead, fSubsessionsTail, guessRTPTimestampFrequency(), lookupPayloadFormat(), NULL, MediaSubsession::parseSDPAttribute_control(), parseSDPAttribute_control(), MediaSubsession::parseSDPAttribute_fmtp(), MediaSubsession::parseSDPAttribute_framerate(), MediaSubsession::parseSDPAttribute_range(), parseSDPAttribute_range(), MediaSubsession::parseSDPAttribute_rtpmap(), MediaSubsession::parseSDPAttribute_source_filter(), parseSDPAttribute_source_filter(), parseSDPAttribute_type(), MediaSubsession::parseSDPAttribute_x_dimensions(), parseSDPLine(), MediaSubsession::parseSDPLine_b(), MediaSubsession::parseSDPLine_c(), parseSDPLine_c(), parseSDPLine_i(), parseSDPLine_s(), MediaSubsession::serverPortNum, MediaSubsession::setNext(), UsageEnvironment::setResultMsg(), strDup(), strDupSize(), subsession, and True.

Referenced by createNew().

00099                                                                   {
00100   if (sdpDescription == NULL) return False;
00101
00102   // Begin by processing all SDP lines until we see the first "m="
00103   char const* sdpLine = sdpDescription;
00104   char const* nextSDPLine;
00105   while (1) {
00106     if (!parseSDPLine(sdpLine, nextSDPLine)) return False;
00107     //##### We should really check for:
00108     // - "a=control:" attributes (to set the URL for aggregate control)
00109     // - the correct SDP version (v=0)
00110     if (sdpLine[0] == 'm') break;
00111     sdpLine = nextSDPLine;
00112     if (sdpLine == NULL) break; // there are no m= lines at all
00113
00114     // Check for various special SDP lines that we understand:
00115     if (parseSDPLine_s(sdpLine)) continue;
00116     if (parseSDPLine_i(sdpLine)) continue;
00117     if (parseSDPLine_c(sdpLine)) continue;
00118     if (parseSDPAttribute_control(sdpLine)) continue;
00119     if (parseSDPAttribute_range(sdpLine)) continue;
00120     if (parseSDPAttribute_type(sdpLine)) continue;
00121     if (parseSDPAttribute_source_filter(sdpLine)) continue;
00122   }
00123
00124   while (sdpLine != NULL) {
00125     // We have a "m=" line, representing a new sub-session:
00126     MediaSubsession* subsession = createNewMediaSubsession();
00127     if (subsession == NULL) {
00128       envir().setResultMsg("Unable to create new MediaSubsession");
00129       return False;
00130     }
00131
00132     // Parse the line as "m=<medium_name> <client_portNum> RTP/AVP <fmt>"
00133     // or "m=<medium_name> <client_portNum>/<num_ports> RTP/AVP <fmt>"
00134     // (Should we be checking for >1 payload format number here?)#####
00135     char* mediumName = strDupSize(sdpLine); // ensures we have enough space
00136     char const* protocolName = NULL;
00137     unsigned payloadFormat;
00138     if ((sscanf(sdpLine, "m=%s %hu RTP/AVP %u",
00139                 mediumName, &subsession->fClientPortNum, &payloadFormat) == 3 ||
00140          sscanf(sdpLine, "m=%s %hu/%*u RTP/AVP %u",
00141                 mediumName, &subsession->fClientPortNum, &payloadFormat) == 3)
00142         && payloadFormat <= 127) {
00143       protocolName = "RTP";
00144     } else if ((sscanf(sdpLine, "m=%s %hu UDP %u",
00145                        mediumName, &subsession->fClientPortNum, &payloadFormat) == 3 ||
00146                 sscanf(sdpLine, "m=%s %hu udp %u",
00147                        mediumName, &subsession->fClientPortNum, &payloadFormat) == 3 ||
00148                 sscanf(sdpLine, "m=%s %hu RAW/RAW/UDP %u",
00149                        mediumName, &subsession->fClientPortNum, &payloadFormat) == 3)
00150                && payloadFormat <= 127) {
00151       // This is a RAW UDP source
00152       protocolName = "UDP";
00153     } else {
00154       // This "m=" line is bad; output an error message saying so:
00155       char* sdpLineStr;
00156       if (nextSDPLine == NULL) {
00157         sdpLineStr = (char*)sdpLine;
00158       } else {
00159         sdpLineStr = strDup(sdpLine);
00160         sdpLineStr[nextSDPLine-sdpLine] = '\0';
00161       }
00162       envir() << "Bad SDP \"m=\" line: " <<  sdpLineStr << "\n";
00163       if (sdpLineStr != (char*)sdpLine) delete[] sdpLineStr;
00164
00165       delete[] mediumName;
00166       delete subsession;
00167
00168       // Skip the following SDP lines, up until the next "m=":
00169       while (1) {
00170         sdpLine = nextSDPLine;
00171         if (sdpLine == NULL) break; // we've reached the end
00172         if (!parseSDPLine(sdpLine, nextSDPLine)) return False;
00173
00174         if (sdpLine[0] == 'm') break; // we've reached the next subsession
00175       }
00176       continue;
00177     }
00178
00179     // Insert this subsession at the end of the list:
00180     if (fSubsessionsTail == NULL) {
00181       fSubsessionsHead = fSubsessionsTail = subsession;
00182     } else {
00183       fSubsessionsTail->setNext(subsession);
00184       fSubsessionsTail = subsession;
00185     }
00186
00187     subsession->serverPortNum = subsession->fClientPortNum; // by default
00188
00189     char const* mStart = sdpLine;
00190     subsession->fSavedSDPLines = strDup(mStart);
00191
00192     subsession->fMediumName = strDup(mediumName);
00193     delete[] mediumName;
00194     subsession->fProtocolName = strDup(protocolName);
00195     subsession->fRTPPayloadFormat = payloadFormat;
00196
00197     // Process the following SDP lines, up until the next "m=":
00198     while (1) {
00199       sdpLine = nextSDPLine;
00200       if (sdpLine == NULL) break; // we've reached the end
00201       if (!parseSDPLine(sdpLine, nextSDPLine)) return False;
00202
00203       if (sdpLine[0] == 'm') break; // we've reached the next subsession
00204
00205       // Check for various special SDP lines that we understand:
00206       if (subsession->parseSDPLine_c(sdpLine)) continue;
00207       if (subsession->parseSDPLine_b(sdpLine)) continue;
00208       if (subsession->parseSDPAttribute_rtpmap(sdpLine)) continue;
00209       if (subsession->parseSDPAttribute_control(sdpLine)) continue;
00210       if (subsession->parseSDPAttribute_range(sdpLine)) continue;
00211       if (subsession->parseSDPAttribute_fmtp(sdpLine)) continue;
00212       if (subsession->parseSDPAttribute_source_filter(sdpLine)) continue;
00213       if (subsession->parseSDPAttribute_x_dimensions(sdpLine)) continue;
00214       if (subsession->parseSDPAttribute_framerate(sdpLine)) continue;
00215
00216       // (Later, check for malformed lines, and other valid SDP lines#####)
00217     }
00218     if (sdpLine != NULL) subsession->fSavedSDPLines[sdpLine-mStart] = '\0';
00219
00220     // If we don't yet know the codec name, try looking it up from the
00221     // list of static payload types:
00222     if (subsession->fCodecName == NULL) {
00223       subsession->fCodecName
00224         = lookupPayloadFormat(subsession->fRTPPayloadFormat,
00225                               subsession->fRTPTimestampFrequency,
00226                               subsession->fNumChannels);
00227       if (subsession->fCodecName == NULL) {
00228         char typeStr[20];
00229         sprintf(typeStr, "%d", subsession->fRTPPayloadFormat);
00230         envir().setResultMsg("Unknown codec name for RTP payload type ",
00231                              typeStr);
00232         return False;
00233       }
00234     }
00235
00236     // If we don't yet know this subsession's RTP timestamp frequency
00237     // (because it uses a dynamic payload type and the corresponding
00238     // SDP "rtpmap" attribute erroneously didn't specify it),
00239     // then guess it now:
00240     if (subsession->fRTPTimestampFrequency == 0) {
00241       subsession->fRTPTimestampFrequency
00242         = guessRTPTimestampFrequency(subsession->fMediumName,
00243                                      subsession->fCodecName);
00244     }
00245   }
00246
00247   return True;
00248 }

Boolean MediaSession::parseSDPLine ( char const *  input,
char const *&  nextLine
) [protected]

Definition at line 250 of file MediaSession.cpp.

References Medium::envir(), False, NULL, and True.

Referenced by initializeWithSDP().

00251                                                          {
00252   // Begin by finding the start of the next line (if any):
00253   nextLine = NULL;
00254   for (char const* ptr = inputLine; *ptr != '\0'; ++ptr) {
00255     if (*ptr == '\r' || *ptr == '\n') {
00256       // We found the end of the line
00257       ++ptr;
00258       while (*ptr == '\r' || *ptr == '\n') ++ptr;
00259       nextLine = ptr;
00260       if (nextLine[0] == '\0') nextLine = NULL; // special case for end
00261       break;
00262     }
00263   }
00264
00265   // Then, check that this line is a SDP line of the form <char>=<etc>
00266   // (However, we also accept blank lines in the input.)
00267   if (inputLine[0] == '\r' || inputLine[0] == '\n') return True;
00268   if (strlen(inputLine) < 2 || inputLine[1] != '='
00269       || inputLine[0] < 'a' || inputLine[0] > 'z') {
00270     envir().setResultMsg("Invalid SDP line: ", inputLine);
00271     return False;
00272   }
00273
00274   return True;
00275 }

Boolean MediaSession::parseSDPLine_s ( char const *  sdpLine  )  [protected]

Definition at line 289 of file MediaSession.cpp.

References False, fSessionName, strDup(), strDupSize(), and True.

Referenced by initializeWithSDP().

00289                                                         {
00290   // Check for "s=<session name>" line
00291   char* buffer = strDupSize(sdpLine);
00292   Boolean parseSuccess = False;
00293
00294   if (sscanf(sdpLine, "s=%[^\r\n]", buffer) == 1) {
00295     delete[] fSessionName; fSessionName = strDup(buffer);
00296     parseSuccess = True;
00297   }
00298   delete[] buffer;
00299
00300   return parseSuccess;
00301 }

Boolean MediaSession::parseSDPLine_i ( char const *  sdpLine  )  [protected]

Definition at line 303 of file MediaSession.cpp.

References False, fSessionDescription, strDup(), strDupSize(), and True.

Referenced by initializeWithSDP().

00303                                                         {
00304   // Check for "i=<session description>" line
00305   char* buffer = strDupSize(sdpLine);
00306   Boolean parseSuccess = False;
00307
00308   if (sscanf(sdpLine, "i=%[^\r\n]", buffer) == 1) {
00309     delete[] fSessionDescription; fSessionDescription = strDup(buffer);
00310     parseSuccess = True;
00311   }
00312   delete[] buffer;
00313
00314   return parseSuccess;
00315 }

Boolean MediaSession::parseSDPLine_c ( char const *  sdpLine  )  [protected]

Definition at line 317 of file MediaSession.cpp.

References connectionEndpointName(), False, fConnectionEndpointName, NULL, parseCLine(), and True.

Referenced by initializeWithSDP().

00317                                                         {
00318   // Check for "c=IN IP4 <connection-endpoint>"
00319   // or "c=IN IP4 <connection-endpoint>/<ttl+numAddresses>"
00320   // (Later, do something with <ttl+numAddresses> also #####)
00321   char* connectionEndpointName = parseCLine(sdpLine);
00322   if (connectionEndpointName != NULL) {
00323     delete[] fConnectionEndpointName;
00324     fConnectionEndpointName = connectionEndpointName;
00325     return True;
00326   }
00327
00328   return False;
00329 }

Boolean MediaSession::parseSDPAttribute_type ( char const *  sdpLine  )  [protected]

Definition at line 331 of file MediaSession.cpp.

References False, fMediaSessionType, strDup(), strDupSize(), and True.

Referenced by initializeWithSDP().

00331                                                                 {
00332   // Check for a "a=type:broadcast|meeting|moderated|test|H.332|recvonly" line:
00333   Boolean parseSuccess = False;
00334
00335   char* buffer = strDupSize(sdpLine);
00336   if (sscanf(sdpLine, "a=type: %[^ ]", buffer) == 1) {
00337     delete[] fMediaSessionType;
00338     fMediaSessionType = strDup(buffer);
00339     parseSuccess = True;
00340   }
00341   delete[] buffer;
00342
00343   return parseSuccess;
00344 }

Boolean MediaSession::parseSDPAttribute_control ( char const *  sdpLine  )  [protected]

Definition at line 350 of file MediaSession.cpp.

References controlPath(), False, fControlPath, strDup(), strDupSize(), and True.

Referenced by initializeWithSDP().

00350                                                                    {
00351   // Check for a "a=control:<control-path>" line:
00352   Boolean parseSuccess = False;
00353
00354   char* controlPath = strDupSize(sdpLine); // ensures we have enough space
00355   if (sscanf(sdpLine, "a=control: %s", controlPath) == 1) {
00356     parseSuccess = True;
00357     delete[] fControlPath; fControlPath = strDup(controlPath);
00358   }
00359   delete[] controlPath;
00360
00361   return parseSuccess;
00362 }

Boolean MediaSession::parseSDPAttribute_range ( char const *  sdpLine  )  [protected]

Definition at line 364 of file MediaSession.cpp.

References False, fMaxPlayEndTime, fMaxPlayStartTime, parseRangeAttribute(), playEndTime(), playStartTime(), and True.

Referenced by initializeWithSDP().

00364                                                                  {
00365   // Check for a "a=range:npt=<startTime>-<endTime>" line:
00366   // (Later handle other kinds of "a=range" attributes also???#####)
00367   Boolean parseSuccess = False;
00368
00369   double playStartTime;
00370   double playEndTime;
00371   if (parseRangeAttribute(sdpLine, playStartTime, playEndTime)) {
00372     parseSuccess = True;
00373     if (playStartTime > fMaxPlayStartTime) {
00374       fMaxPlayStartTime = playStartTime;
00375     }
00376     if (playEndTime > fMaxPlayEndTime) {
00377       fMaxPlayEndTime = playEndTime;
00378     }
00379   }
00380
00381   return parseSuccess;
00382 }

Boolean MediaSession::parseSDPAttribute_source_filter ( char const *  sdpLine  )  [protected]

Definition at line 413 of file MediaSession.cpp.

References fSourceFilterAddr, and parseSourceFilterAttribute().

Referenced by initializeWithSDP().

00413                                                      {
00414   return parseSourceFilterAttribute(sdpLine, fSourceFilterAddr);
00415 }

char * MediaSession::lookupPayloadFormat ( unsigned char  rtpPayloadType,
unsigned &  rtpTimestampFrequency,
unsigned &  numChannels
) [static, protected]

Definition at line 417 of file MediaSession.cpp.

References NULL, and strDup().

Referenced by initializeWithSDP().

00418                                                                        {
00419   // Look up the codec name and timestamp frequency for known (static)
00420   // RTP payload formats.
00421   char const* temp = NULL;
00422   switch (rtpPayloadType) {
00423   case 0: {temp = "PCMU"; freq = 8000; nCh = 1; break;}
00424   case 2: {temp = "G726-32"; freq = 8000; nCh = 1; break;}
00425   case 3: {temp = "GSM"; freq = 8000; nCh = 1; break;}
00426   case 4: {temp = "G723"; freq = 8000; nCh = 1; break;}
00427   case 5: {temp = "DVI4"; freq = 8000; nCh = 1; break;}
00428   case 6: {temp = "DVI4"; freq = 16000; nCh = 1; break;}
00429   case 7: {temp = "LPC"; freq = 8000; nCh = 1; break;}
00430   case 8: {temp = "PCMA"; freq = 8000; nCh = 1; break;}
00431   case 9: {temp = "G722"; freq = 8000; nCh = 1; break;}
00432   case 10: {temp = "L16"; freq = 44100; nCh = 2; break;}
00433   case 11: {temp = "L16"; freq = 44100; nCh = 1; break;}
00434   case 12: {temp = "QCELP"; freq = 8000; nCh = 1; break;}
00435   case 14: {temp = "MPA"; freq = 90000; nCh = 1; break;}
00436     // 'number of channels' is actually encoded in the media stream
00437   case 15: {temp = "G728"; freq = 8000; nCh = 1; break;}
00438   case 16: {temp = "DVI4"; freq = 11025; nCh = 1; break;}
00439   case 17: {temp = "DVI4"; freq = 22050; nCh = 1; break;}
00440   case 18: {temp = "G729"; freq = 8000; nCh = 1; break;}
00441   case 25: {temp = "CELB"; freq = 90000; nCh = 1; break;}
00442   case 26: {temp = "JPEG"; freq = 90000; nCh = 1; break;}
00443   case 28: {temp = "NV"; freq = 90000; nCh = 1; break;}
00444   case 31: {temp = "H261"; freq = 90000; nCh = 1; break;}
00445   case 32: {temp = "MPV"; freq = 90000; nCh = 1; break;}
00446   case 33: {temp = "MP2T"; freq = 90000; nCh = 1; break;}
00447   case 34: {temp = "H263"; freq = 90000; nCh = 1; break;}
00448   };
00449
00450   return strDup(temp);
00451 }

unsigned MediaSession::guessRTPTimestampFrequency ( char const *  mediumName,
char const *  codecName
) [static, protected]

Definition at line 453 of file MediaSession.cpp.

Referenced by initializeWithSDP().

00454                                                                          {
00455   // By default, we assume that audio sessions use a frequency of 8000,
00456   // video sessions use a frequency of 90000,
00457   // and text sessions use a frequency of 1000.
00458   // Begin by checking for known exceptions to this rule
00459   // (where the frequency is known unambiguously (e.g., not like "DVI4"))
00460   if (strcmp(codecName, "L16") == 0) return 44100;
00461   if (strcmp(codecName, "MPA") == 0
00462       || strcmp(codecName, "MPA-ROBUST") == 0
00463       || strcmp(codecName, "X-MP3-DRAFT-00")) return 90000;
00464
00465   // Now, guess default values:
00466   if (strcmp(mediumName, "video") == 0) return 90000;
00467   else if (strcmp(mediumName, "text") == 0) return 1000;
00468   return 8000; // for "audio", and any other medium
00469 }

Boolean Medium::lookupByName ( UsageEnvironment &  env,
char const *  mediumName,
Medium *&  resultMedium
) [static, inherited]

Definition at line 41 of file Media.cpp.

References env, False, MediaLookupTable::lookup(), NULL, MediaLookupTable::ourMedia(), UsageEnvironment::setResultMsg(), and True.

Referenced by ServerMediaSession::lookupByName(), RTSPServer::lookupByName(), RTSPClient::lookupByName(), RTCPInstance::lookupByName(), MediaSource::lookupByName(), MediaSink::lookupByName(), lookupByName(), and DarwinInjector::lookupByName().

00042                                                          {
00043   resultMedium = MediaLookupTable::ourMedia(env)->lookup(mediumName);
00044   if (resultMedium == NULL) {
00045     env.setResultMsg("Medium ", mediumName, " does not exist");
00046     return False;
00047   }
00048
00049   return True;
00050 }

void Medium::close ( UsageEnvironment &  env,
char const *  mediumName
) [static, inherited]

Definition at line 52 of file Media.cpp.

References env, MediaLookupTable::ourMedia(), and MediaLookupTable::remove().

Referenced by afterPlaying(), Medium::close(), closeMediaSinks(), OnDemandServerMediaSubsession::closeStreamSource(), continueAfterTEARDOWN(), WAVAudioFileSource::createNew(), QuickTimeFileSink::createNew(), QCELPAudioRTPSource::createNew(), MP3HTTPSource::createNew(), MP3FileSource::createNew(), AVIFileSink::createNew(), AMRAudioRTPSource::createNew(), WAVAudioFileServerMediaSubsession::createNewStreamSource(), MPEG1or2DemuxedServerMediaSubsession::createNewStreamSource(), MediaSubsession::deInitiate(), RTSPServerSupportingHTTPStreaming::RTSPClientSessionSupportingHTTPStreaming::handleHTTPCmd_StreamingGET(), MediaSubsession::initiate(), MPEG1or2ProgramStreamFileDuration(), MPEG1or2Demux::noteElementaryStreamDeletion(), ByteStreamMultiFileSource::onSourceClosure1(), StreamState::reclaim(), RTSPServer::removeServerMediaSession(), OnDemandServerMediaSubsession::sdpLines(), shutdownStream(), T140TextRTPSink::stopPlaying(), H264VideoRTPSink::stopPlaying(), subsessionAfterPlaying(), ClientTrickPlayState::updateStateOnScaleChange(), AMRDeinterleaver::~AMRDeinterleaver(), ByteStreamMultiFileSource::~ByteStreamMultiFileSource(), DarwinInjector::~DarwinInjector(), FramedFilter::~FramedFilter(), InputESSourceRecord::~InputESSourceRecord(), MatroskaFileParser::~MatroskaFileParser(), MatroskaFileServerDemux::~MatroskaFileServerDemux(), MPEG1or2Demux::~MPEG1or2Demux(), MPEG1or2FileServerDemux::~MPEG1or2FileServerDemux(), MPEG2TransportFileServerMediaSubsession::~MPEG2TransportFileServerMediaSubsession(), MPEG2TransportStreamFromPESSource::~MPEG2TransportStreamFromPESSource(), RTSPServerSupportingHTTPStreaming::RTSPClientSessionSupportingHTTPStreaming::~RTSPClientSessionSupportingHTTPStreaming(), ServerMediaSession::~ServerMediaSession(), ServerMediaSubsession::~ServerMediaSubsession(), StreamClientState::~StreamClientState(), and StreamReplicator::~StreamReplicator().

00052                                                           {
00053   MediaLookupTable::ourMedia(env)->remove(name);
00054 }

void Medium::close ( Medium *  medium  )  [static, inherited]

Definition at line 56 of file Media.cpp.

References Medium::close(), Medium::envir(), Medium::name(), and NULL.

00056                                  {
00057   if (medium == NULL) return;
00058
00059   close(medium->envir(), medium->name());
00060 }

UsageEnvironment& Medium::envir (  )  const [inline, inherited]

Definition at line 59 of file Media.hh.

References Medium::fEnviron.

Referenced by QuickTimeFileSink::addArbitraryString(), FileSink::addData(), RTCPInstance::addStreamSocket(), MPEG2IFrameIndexFromTransportStream::addToTail(), StreamParser::afterGettingBytes1(), DummySink::afterGettingFrame(), T140IdleFilter::afterGettingFrame(), MultiFramedRTPSink::afterGettingFrame1(), InputESSourceRecord::afterGettingFrame1(), MPEG2TransportStreamFramer::afterGettingFrame1(), MPEG2IFrameIndexFromTransportStream::afterGettingFrame1(), H264VideoStreamDiscreteFramer::afterGettingFrame1(), BasicUDPSink::afterGettingFrame1(), MPEG4VideoFileServerMediaSubsession::afterPlayingDummy1(), H264VideoFileServerMediaSubsession::afterPlayingDummy1(), MPEG4VideoStreamParser::analyzeVOLHeader(), announceStream(), RTSPServer::RTSPClientSession::changeClientInputSocket(), MPEG4VideoFileServerMediaSubsession::checkForAuxSDPLine1(), H264VideoFileServerMediaSubsession::checkForAuxSDPLine1(), Medium::close(), MPEG2IFrameIndexFromTransportStream::compactParseBuffer(), RTSPClient::connectionHandler1(), RTSPClient::connectToServer(), T140TextRTPSink::continuePlaying(), QuickTimeFileSink::continuePlaying(), H264VideoRTPSink::continuePlaying(), AVIFileSink::continuePlaying(), VP8VideoMatroskaFileServerMediaSubsession::createNewRTPSink(), VorbisAudioMatroskaFileServerMediaSubsession::createNewRTPSink(), T140TextMatroskaFileServerMediaSubsession::createNewRTPSink(), MPEG4VideoFileServerMediaSubsession::createNewRTPSink(), MPEG2TransportUDPServerMediaSubsession::createNewRTPSink(), MPEG2TransportFileServerMediaSubsession::createNewRTPSink(), MPEG1or2VideoFileServerMediaSubsession::createNewRTPSink(), MPEG1or2DemuxedServerMediaSubsession::createNewRTPSink(), MP3AudioFileServerMediaSubsession::createNewRTPSink(), H264VideoFileServerMediaSubsession::createNewRTPSink(), H263plusVideoFileServerMediaSubsession::createNewRTPSink(), DVVideoFileServerMediaSubsession::createNewRTPSink(), AMRAudioFileServerMediaSubsession::createNewRTPSink(), ADTSAudioFileServerMediaSubsession::createNewRTPSink(), AC3AudioMatroskaFileServerMediaSubsession::createNewRTPSink(), AC3AudioFileServerMediaSubsession::createNewRTPSink(), AACAudioMatroskaFileServerMediaSubsession::createNewRTPSink(), MPEG4VideoFileServerMediaSubsession::createNewStreamSource(), MPEG2TransportUDPServerMediaSubsession::createNewStreamSource(), MPEG2TransportFileServerMediaSubsession::createNewStreamSource(), MPEG1or2VideoFileServerMediaSubsession::createNewStreamSource(), MPEG1or2DemuxedServerMediaSubsession::createNewStreamSource(), MP3AudioFileServerMediaSubsession::createNewStreamSource(), H264VideoMatroskaFileServerMediaSubsession::createNewStreamSource(), H264VideoFileServerMediaSubsession::createNewStreamSource(), H263plusVideoFileServerMediaSubsession::createNewStreamSource(), DVVideoFileServerMediaSubsession::createNewStreamSource(), AMRAudioFileServerMediaSubsession::createNewStreamSource(), ADTSAudioFileServerMediaSubsession::createNewStreamSource(), AC3AudioFileServerMediaSubsession::createNewStreamSource(), AMRDeinterleavingBuffer::deliverIncomingFrame(), MPEG2IFrameIndexFromTransportStream::deliverIndexRecord(), SegmentQueue::dequeue(), DeviceSource::DeviceSource(), WAVAudioFileSource::doGetNextFrame(), T140IdleFilter::doGetNextFrame(), MPEG2IFrameIndexFromTransportStream::doGetNextFrame(), MP3FileSource::doGetNextFrame(), H264FUAFragmenter::doGetNextFrame(), ByteStreamMultiFileSource::doGetNextFrame(), ByteStreamFileSource::doGetNextFrame(), BasicUDPSource::doGetNextFrame(), AMRAudioFileSource::doGetNextFrame(), ADTSAudioFileSource::doGetNextFrame(), MultiFramedRTPSource::doGetNextFrame1(), MP3FileSource::doGetNextFrame1(), ADUFromMP3Source::doGetNextFrame1(), SIPClient::doInviteStateMachine(), ByteStreamFileSource::doReadFromFile(), MPEG1or2VideoRTPSink::doSpecialFrameHandling(), MP3ADURTPSink::doSpecialFrameHandling(), H263plusVideoRTPSink::doSpecialFrameHandling(), T140IdleFilter::doStopGettingFrames(), ByteStreamFileSource::doStopGettingFrames(), BasicUDPSource::doStopGettingFrames(), SegmentQueue::enqueueNewSegment(), StreamParser::ensureValidBytes1(), MediaSubsession::env(), SubsessionIOState::envir(), RTSPServer::RTSPClientSession::envir(), RTPInterface::envir(), AVISubsessionIOState::envir(), ServerMediaSession::generateSDPDescription(), RTPSource::getAttributes(), MP3FileSource::getAttributes(), MP3ADUTranscoder::getAttributes(), MediaSource::getAttributes(), MPEG4VideoFileServerMediaSubsession::getAuxSDPLine(), H264VideoFileServerMediaSubsession::getAuxSDPLine(), getMPEG1or2TimeCode(), FramedSource::getNextFrame(), getOptions(), DVVideoStreamFramer::getProfile(), SIPClient::getResponse(), SIPClient::getResponseCode(), getSDPDescription(), OnDemandServerMediaSubsession::getStreamParameters(), RTSPClient::handleGET_PARAMETERResponse(), RTSPServerSupportingHTTPStreaming::RTSPClientSessionSupportingHTTPStreaming::handleHTTPCmd_StreamingGET(), RTSPClient::handleIncomingRequest(), RTSPClient::handlePLAYResponse(), RTSPClient::handleRequestError(), RTSPClient::handleResponseBytes(), RTSPClient::handleSETUPResponse(), RTSPServer::incomingConnectionHandler(), RTSPClient::incomingDataHandler1(), RTCPInstance::incomingReportHandler1(), MP3FileSource::initializeStream(), initializeWithSDP(), initiateByMediaType(), SIPClient::invite1(), DynamicRTSPServer::lookupServerMediaSession(), MatroskaDemux::MatroskaDemux(), MatroskaFile::MatroskaFile(), MPEG4GenericRTPSource::MPEG4GenericRTPSource(), MatroskaDemux::newDemuxedTrack(), MPEG1or2FileServerDemux::newElementaryStream(), MPEG1or2Demux::newElementaryStream(), MPEG4GenericBufferedPacket::nextEnclosedFrameSize(), AMRBufferedPacket::nextEnclosedFrameSize(), RTSPClient::openConnection(), MPEG2TransportStreamIndexFile::openFid(), MPEG2IFrameIndexFromTransportStream::parseFrame(), AC3AudioStreamParser::parseFrame(), MPEGProgramStreamParser::parsePackHeader(), MPEGProgramStreamParser::parsePESPacket(), SIPClient::parseResponseCode(), parseSDPLine(), MPEG1or2VideoStreamParser::parseSlice(), MatroskaFileParser::parseStartOfFile(), MPEGProgramStreamParser::parseSystemHeader(), MPEG4VideoStreamParser::parseVideoObjectLayer(), MPEG4VideoStreamParser::parseVideoObjectPlane(), MPEG4VideoStreamParser::parseVisualObject(), TCPStreamSink::processBuffer(), SIPClient::processURL(), AC3AudioStreamParser::readAndSaveAFrame(), MPEG1or2Demux::registerReadInterest(), RTCPInstance::reschedule(), RTSPClient::resendCommand(), RTSPClient::resetTCPSockets(), RTSPClient::responseHandlerForHTTP_GET1(), RTSPServer::rtspURLPrefix(), RTCPInstance::schedule(), OnDemandServerMediaSubsession::sdpLines(), SIPClient::sendACK(), SIPClient::sendBYE(), SIPClient::sendINVITE(), MultiFramedRTPSink::sendPacketIfNecessary(), SIPClient::sendRequest(), RTSPClient::sendRequest(), DarwinInjector::setDestination(), RTSPClient::setupHTTPTunneling1(), setupNextSubsession(), RTSPServer::setUpTunnelingOverHTTP(), QuickTimeFileSink::setWord(), AVIFileSink::setWord(), QuickTimeFileSink::setWord64(), shutdownStream(), SIPClient::SIPClient(), TCPStreamSink::socketWritableHandler1(), AMRAudioRTPSink::sourceIsCompatibleWithUs(), QuickTimeFileSink::startPlaying(), StreamState::startPlaying(), MediaSink::startPlaying(), AVIFileSink::startPlaying(), startPlayingSession(), PassiveServerMediaSubsession::startStream(), MediaSink::stopPlaying(), tearDownSession(), SIPClient::timerAHandler(), SIPClient::timerBHandler(), SIPClient::timerDHandler(), ClientTrickPlayState::updateStateOnScaleChange(), MPEG2TransportStreamFramer::updateTSPacketDurationEstimate(), BasicUDPSource::~BasicUDPSource(), ByteStreamFileSource::~ByteStreamFileSource(), DeviceSource::~DeviceSource(), RTSPServer::~RTSPServer(), StreamClientState::~StreamClientState(), and T140IdleFilter::~T140IdleFilter().

00059 {return fEnviron;}

char const* Medium::name (  )  const [inline, inherited]

Definition at line 61 of file Media.hh.

References Medium::fMediumName.

Referenced by QuickTimeFileSink::addAtom_hdlr2(), Medium::close(), MP3ADUTranscoder::createNew(), MP3FromADUSource::createNew(), ADUFromMP3Source::createNew(), and MP3FileSource::initializeStream().

00061 {return fMediumName;}

Boolean Medium::isSource (  )  const [virtual, inherited]

Reimplemented in MediaSource.

Definition at line 62 of file Media.cpp.

References False.

Referenced by MediaSource::lookupByName().

00062                                {
00063   return False; // default implementation
00064 }

Boolean Medium::isSink (  )  const [virtual, inherited]

Reimplemented in MediaSink.

Definition at line 66 of file Media.cpp.

References False.

Referenced by MediaSink::lookupByName().

00066                              {
00067   return False; // default implementation
00068 }

Boolean Medium::isRTCPInstance (  )  const [virtual, inherited]

Reimplemented in RTCPInstance.

Definition at line 70 of file Media.cpp.

References False.

Referenced by RTCPInstance::lookupByName().

00070                                      {
00071   return False; // default implementation
00072 }

Boolean Medium::isRTSPClient (  )  const [virtual, inherited]

Reimplemented in RTSPClient.

Definition at line 74 of file Media.cpp.

References False.

Referenced by RTSPClient::lookupByName().

00074                                    {
00075   return False; // default implementation
00076 }

Boolean Medium::isRTSPServer (  )  const [virtual, inherited]

Reimplemented in RTSPServer.

Definition at line 78 of file Media.cpp.

References False.

Referenced by RTSPServer::lookupByName().

00078                                    {
00079   return False; // default implementation
00080 }

Boolean Medium::isServerMediaSession (  )  const [virtual, inherited]

Reimplemented in ServerMediaSession.

Definition at line 86 of file Media.cpp.

References False.

Referenced by ServerMediaSession::lookupByName().

00086                                            {
00087   return False; // default implementation
00088 }

Boolean Medium::isDarwinInjector (  )  const [virtual, inherited]

Reimplemented in DarwinInjector.

Definition at line 90 of file Media.cpp.

References False.

Referenced by DarwinInjector::lookupByName().

00090                                        {
00091   return False; // default implementation
00092 }

TaskToken& Medium::nextTask (  )  [inline, protected, inherited]

Definition at line 78 of file Media.hh.

References Medium::fNextTask.

Referenced by BasicUDPSink::afterGettingFrame1(), MPEG4VideoFileServerMediaSubsession::afterPlayingDummy1(), H264VideoFileServerMediaSubsession::afterPlayingDummy1(), MPEG4VideoFileServerMediaSubsession::checkForAuxSDPLine1(), H264VideoFileServerMediaSubsession::checkForAuxSDPLine1(), WAVAudioFileSource::doGetNextFrame(), MP3FileSource::doGetNextFrame(), AMRAudioFileSource::doGetNextFrame(), ADTSAudioFileSource::doGetNextFrame(), MultiFramedRTPSource::doGetNextFrame1(), ByteStreamFileSource::doReadFromFile(), RTCPInstance::reschedule(), RTCPInstance::schedule(), MultiFramedRTPSink::sendPacketIfNecessary(), and MediaSink::stopPlaying().

00078                         {
00079         return fNextTask;
00080   }

Friends And Related Function Documentation

friend class MediaSubsessionIterator [friend]

Definition at line 108 of file MediaSession.hh.

friend class MediaLookupTable [friend, inherited]

Definition at line 74 of file Media.hh.

Field Documentation

char* MediaSession::fCNAME [protected]

Definition at line 109 of file MediaSession.hh.

Referenced by CNAME(), MediaSession(), and ~MediaSession().

MediaSubsession* MediaSession::fSubsessionsHead [protected]

Definition at line 112 of file MediaSession.hh.

Referenced by hasSubsessions(), initializeWithSDP(), MediaSubsessionIterator::reset(), and ~MediaSession().

MediaSubsession* MediaSession::fSubsessionsTail [protected]

Definition at line 113 of file MediaSession.hh.

Referenced by initializeWithSDP().

char* MediaSession::fConnectionEndpointName [protected]

Definition at line 116 of file MediaSession.hh.

Referenced by connectionEndpointName(), parseSDPLine_c(), and ~MediaSession().

double MediaSession::fMaxPlayStartTime [protected]

Definition at line 117 of file MediaSession.hh.

Referenced by parseSDPAttribute_range(), and playStartTime().

double MediaSession::fMaxPlayEndTime [protected]

Definition at line 118 of file MediaSession.hh.

Referenced by parseSDPAttribute_range(), and playEndTime().

struct in_addr MediaSession::fSourceFilterAddr [read, protected]

Definition at line 119 of file MediaSession.hh.

Referenced by MediaSession(), parseSDPAttribute_source_filter(), and sourceFilterAddr().

float MediaSession::fScale [protected]

Definition at line 120 of file MediaSession.hh.

Referenced by scale().

char* MediaSession::fMediaSessionType [protected]

Definition at line 121 of file MediaSession.hh.

Referenced by mediaSessionType(), parseSDPAttribute_type(), and ~MediaSession().

char* MediaSession::fSessionName [protected]

Definition at line 122 of file MediaSession.hh.

Referenced by parseSDPLine_s(), sessionName(), and ~MediaSession().

char* MediaSession::fSessionDescription [protected]

Definition at line 123 of file MediaSession.hh.

Referenced by parseSDPLine_i(), sessionDescription(), and ~MediaSession().

char* MediaSession::fControlPath [protected]

Definition at line 124 of file MediaSession.hh.

Referenced by controlPath(), parseSDPAttribute_control(), and ~MediaSession().

The documentation for this class was generated from the following files:
Generated on Thu Feb 2 23:55:12 2012 for live by  doxygen 1.5.2
