live: DeviceSource Class Reference

typedef void( FramedSource::afterGettingFunc)(void *clientData, unsigned frameSize, unsigned numTruncatedBytes, struct timeval presentationTime, unsigned durationInMicroseconds) [inherited]

Definition at line 36 of file FramedSource.hh.

typedef void( FramedSource::onCloseFunc)(void *clientData) [inherited]

Definition at line 40 of file FramedSource.hh.

DeviceSource::DeviceSource	(	UsageEnvironment &	env,
		DeviceParameters	params
	)			`[protected]`

Definition at line 29 of file DeviceSource.cpp.

Referenced by createNew().

00031   : FramedSource(env), fParams(params) {
00032   // Any initialization of the device would be done here
00033 }

DeviceSource::~DeviceSource ( ) [protected, virtual]

Definition at line 35 of file DeviceSource.cpp.

00035                             {
00036 }

DeviceSource * DeviceSource::createNew	(	UsageEnvironment &	env,
		DeviceParameters	params
	)			`[static]`

Definition at line 24 of file DeviceSource.cpp.

References DeviceSource(), and env.

00025                                                  {
00026   return new DeviceSource(env, params);
00027 }

void DeviceSource::doGetNextFrame ( ) [private, virtual]

Implements FramedSource.

Definition at line 38 of file DeviceSource.cpp.

References FramedSource::handleClosure().

00038                                   {
00039   // Arrange here for our "deliverFrame" member function to be called
00040   // when the next frame of data becomes available from the device.
00041   // This must be done in a non-blocking fashion - i.e., so that we
00042   // return immediately from this function even if no data is
00043   // currently available.
00044   //
00045   // If the device can be implemented as a readable socket, then one easy
00046   // way to do this is using a call to
00047   //     envir().taskScheduler().turnOnBackgroundReadHandling( ... )
00048   // (See examples of this call in the "liveMedia" directory.)
00049
00050   // If, for some reason, the source device stops being readable
00051   // (e.g., it gets closed), then you do the following:
00052   if (0 /* the source stops being readable */) {
00053     handleClosure(this);
00054     return;
00055   }
00056 }

void DeviceSource::deliverFrame ( ) [private]

Definition at line 58 of file DeviceSource.cpp.

References FramedSource::afterGetting(), and FramedSource::isCurrentlyAwaitingData().

00058                                 {
00059   // This would be called when new frame data is available from the device.
00060   // This function should deliver the next frame of data from the device,
00061   // using the following parameters (class members):
00062   // 'in' parameters (these should *not* be modified by this function):
00063   //     fTo: The frame data is copied to this address.
00064   //         (Note that the variable "fTo" is *not* modified.  Instead,
00065   //          the frame data is copied to the address pointed to by "fTo".)
00066   //     fMaxSize: This is the maximum number of bytes that can be copied
00067   //         (If the actual frame is larger than this, then it should
00068   //          be truncated, and "fNumTruncatedBytes" set accordingly.)
00069   // 'out' parameters (these are modified by this function):
00070   //     fFrameSize: Should be set to the delivered frame size (<= fMaxSize).
00071   //     fNumTruncatedBytes: Should be set iff the delivered frame would have been
00072   //         bigger than "fMaxSize", in which case it's set to the number of bytes
00073   //         that have been omitted.
00074   //     fPresentationTime: Should be set to the frame's presentation time
00075   //         (seconds, microseconds).
00076   //     fDurationInMicroseconds: Should be set to the frame's duration, if known.
00077   if (!isCurrentlyAwaitingData()) return; // we're not ready for the data yet
00078
00079   // Deliver the data here:
00080
00081   // After delivering the data, inform the reader that it is now available:
00082   FramedSource::afterGetting(this);
00083 }

Boolean FramedSource::lookupByName	(	UsageEnvironment &	env,
		char const *	sourceName,
		FramedSource *&	resultSource
	)			`[static, inherited]`

Definition at line 41 of file FramedSource.cpp.

References env, False, MediaSource::isFramedSource(), MediaSource::lookupByName(), NULL, and True.

Referenced by MP3ADUinterleaverBase::getInputSource().

00042                                                                 {
00043   resultSource = NULL; // unless we succeed
00044
00045   MediaSource* source;
00046   if (!MediaSource::lookupByName(env, sourceName, source)) return False;
00047
00048   if (!source->isFramedSource()) {
00049     env.setResultMsg(sourceName, " is not a framed source");
00050     return False;
00051   }
00052
00053   resultSource = (FramedSource*)source;
00054   return True;
00055 }

Boolean MediaSource::lookupByName	(	UsageEnvironment &	env,
		char const *	sourceName,
		MediaSource *&	resultSource
	)			`[static, inherited]`

Definition at line 65 of file MediaSource.cpp.

References env, False, Medium::isSource(), Medium::lookupByName(), NULL, and True.

Referenced by RTPSource::lookupByName(), and FramedSource::lookupByName().

00067                                                               {
00068   resultSource = NULL; // unless we succeed
00069
00070   Medium* medium;
00071   if (!Medium::lookupByName(env, sourceName, medium)) return False;
00072
00073   if (!medium->isSource()) {
00074     env.setResultMsg(sourceName, " is not a media source");
00075     return False;
00076   }
00077
00078   resultSource = (MediaSource*)medium;
00079   return True;
00080 }

Boolean Medium::lookupByName	(	UsageEnvironment &	env,
		char const *	mediumName,
		Medium *&	resultMedium
	)			`[static, inherited]`

Definition at line 65 of file Media.cpp.

References env, False, MediaLookupTable::lookup(), NULL, MediaLookupTable::ourMedia(), UsageEnvironment::setResultMsg(), and True.

Referenced by ServerMediaSession::lookupByName(), RTSPServer::lookupByName(), RTSPClient::lookupByName(), RTCPInstance::lookupByName(), MediaSource::lookupByName(), MediaSink::lookupByName(), MediaSession::lookupByName(), and DarwinInjector::lookupByName().

00066                                                          {
00067   resultMedium = MediaLookupTable::ourMedia(env)->lookup(mediumName);
00068   if (resultMedium == NULL) {
00069     env.setResultMsg("Medium ", mediumName, " does not exist");
00070     return False;
00071   }
00072
00073   return True;
00074 }

void FramedSource::getNextFrame	(	unsigned char *	to,
		unsigned	maxSize,
		afterGettingFunc *	afterGettingFunc,
		void *	afterGettingClientData,
		onCloseFunc *	onCloseFunc,
		void *	onCloseClientData
	)			`[inherited]`

Definition at line 57 of file FramedSource.cpp.

References FramedSource::doGetNextFrame(), Medium::envir(), FramedSource::fAfterGettingClientData, FramedSource::fAfterGettingFunc, FramedSource::fDurationInMicroseconds, FramedSource::fIsCurrentlyAwaitingData, FramedSource::fMaxSize, FramedSource::fNumTruncatedBytes, FramedSource::fOnCloseClientData, FramedSource::fOnCloseFunc, FramedSource::fTo, and True.

00061                                                          {
00062   // Make sure we're not already being read:
00063   if (fIsCurrentlyAwaitingData) {
00064     envir() << "FramedSource[" << this << "]::getNextFrame(): attempting to read more than once at the same time!\n";
00065     abort();
00066   }
00067
00068   fTo = to;
00069   fMaxSize = maxSize;
00070   fNumTruncatedBytes = 0; // by default; could be changed by doGetNextFrame()
00071   fDurationInMicroseconds = 0; // by default; could be changed by doGetNextFrame()
00072   fAfterGettingFunc = afterGettingFunc;
00073   fAfterGettingClientData = afterGettingClientData;
00074   fOnCloseFunc = onCloseFunc;
00075   fOnCloseClientData = onCloseClientData;
00076   fIsCurrentlyAwaitingData = True;
00077
00078   doGetNextFrame();
00079 }

void FramedSource::handleClosure ( void * clientData ) [static, inherited]

Definition at line 95 of file FramedSource.cpp.

References False, FramedSource::fIsCurrentlyAwaitingData, FramedSource::fOnCloseClientData, FramedSource::fOnCloseFunc, and NULL.

00095                                                  {
00096   FramedSource* source = (FramedSource*)clientData;
00097   source->fIsCurrentlyAwaitingData = False; // because we got a close instead
00098   if (source->fOnCloseFunc != NULL) {
00099     (*(source->fOnCloseFunc))(source->fOnCloseClientData);
00100   }
00101 }

void FramedSource::stopGettingFrames ( ) [inherited]

Definition at line 103 of file FramedSource.cpp.

References FramedSource::doStopGettingFrames(), False, and FramedSource::fIsCurrentlyAwaitingData.

Referenced by MPEG2TransportStreamFromPESSource::doStopGettingFrames(), FramedFilter::doStopGettingFrames(), AMRDeinterleaver::doStopGettingFrames(), and MediaSink::stopPlaying().

00103                                      {
00104   fIsCurrentlyAwaitingData = False; // indicates that we can be read again
00105
00106   // Perform any specialized action now:
00107   doStopGettingFrames();
00108 }

unsigned FramedSource::maxFrameSize ( ) const [virtual, inherited]

Reimplemented in MPEG1or2DemuxedElementaryStream.

Definition at line 116 of file FramedSource.cpp.

Referenced by StreamParser::ensureValidBytes1().

00116                                           {
00117   // By default, this source has no maximum frame size.
00118   return 0;
00119 }

Boolean FramedSource::isCurrentlyAwaitingData ( ) const [inline, inherited]

Definition at line 60 of file FramedSource.hh.

References FramedSource::fIsCurrentlyAwaitingData.

Referenced by afterPlaying(), InputESSourceRecord::askForNewData(), MPEG2TransportStreamFromESSource::awaitNewBuffer(), QuickTimeFileSink::continuePlaying(), AVIFileSink::continuePlaying(), deliverFrame(), QCELPDeinterleaver::doGetNextFrame(), AMRDeinterleaver::doGetNextFrame(), ByteStreamFileSource::fileReadableHandler(), and BasicUDPSource::incomingPacketHandler1().

00060 {return fIsCurrentlyAwaitingData;}

void FramedSource::afterGetting ( FramedSource * source ) [static, protected, inherited]

Definition at line 81 of file FramedSource.cpp.

References FramedSource::fAfterGettingClientData, FramedSource::fAfterGettingFunc, False, FramedSource::fDurationInMicroseconds, FramedSource::fFrameSize, FramedSource::fIsCurrentlyAwaitingData, FramedSource::fNumTruncatedBytes, FramedSource::fPresentationTime, and NULL.

Referenced by ByteStreamMultiFileSource::afterGettingFrame(), EndianSwap16::afterGettingFrame1(), HostFromNetworkOrder16::afterGettingFrame1(), NetworkFromHostOrder16::afterGettingFrame1(), PCMFromuLawAudioSource::afterGettingFrame1(), uLawFromPCMAudioSource::afterGettingFrame1(), MPEG2TransportStreamFramer::afterGettingFrame1(), MPEG1or2DemuxedElementaryStream::afterGettingFrame1(), MP3ADUTranscoder::afterGettingFrame1(), MPEG2TransportStreamTrickModeFilter::attemptDeliveryToClient(), MPEGVideoStreamFramer::continueReadProcessing(), MPEG1or2AudioStreamFramer::continueReadProcessing(), H263plusVideoStreamFramer::continueReadProcessing(), deliverFrame(), MPEG2IFrameIndexFromTransportStream::deliverIndexRecord(), WAVAudioFileSource::doGetNextFrame(), QCELPDeinterleaver::doGetNextFrame(), MPEG2TransportStreamTrickModeFilter::doGetNextFrame(), MPEG2TransportStreamMultiplexor::doGetNextFrame(), MP3FileSource::doGetNextFrame(), MP3ADUdeinterleaver::doGetNextFrame(), MP3ADUinterleaver::doGetNextFrame(), MP3FromADUSource::doGetNextFrame(), H264FUAFragmenter::doGetNextFrame(), DVVideoStreamFramer::doGetNextFrame(), AMRDeinterleaver::doGetNextFrame(), AMRAudioFileSource::doGetNextFrame(), ADTSAudioFileSource::doGetNextFrame(), MultiFramedRTPSource::doGetNextFrame1(), ADUFromMP3Source::doGetNextFrame1(), ByteStreamFileSource::doReadFromFile(), BasicUDPSource::incomingPacketHandler1(), and AC3AudioStreamFramer::parseNextFrame().

00081                                                     {
00082   source->fIsCurrentlyAwaitingData = False;
00083       // indicates that we can be read again
00084       // Note that this needs to be done here, in case the "fAfterFunc"
00085       // called below tries to read another frame (which it usually will)
00086
00087   if (source->fAfterGettingFunc != NULL) {
00088     (*(source->fAfterGettingFunc))(source->fAfterGettingClientData,
00089                                    source->fFrameSize, source->fNumTruncatedBytes,
00090                                    source->fPresentationTime,
00091                                    source->fDurationInMicroseconds);
00092   }
00093 }

void FramedSource::doStopGettingFrames ( ) [protected, virtual, inherited]

Reimplemented in AMRDeinterleaver, BasicUDPSource, ByteStreamFileSource, FramedFilter, MPEG1or2DemuxedElementaryStream, MPEG2TransportStreamFramer, MPEG2TransportStreamFromESSource, MPEG2TransportStreamFromPESSource, MPEG2TransportStreamTrickModeFilter, and MultiFramedRTPSource.

Definition at line 110 of file FramedSource.cpp.

Referenced by FramedSource::stopGettingFrames().

00110                                        {
00111   // Default implementation: Do nothing
00112   // Subclasses may wish to specialize this so as to ensure that a
00113   // subsequent reader can pick up where this one left off.
00114 }

void MediaSource::getAttributes ( ) const [virtual, inherited]

Reimplemented in FramedFilter, MP3ADUTranscoder, MP3FileSource, and RTPSource.

Definition at line 82 of file MediaSource.cpp.

References Medium::envir(), and UsageEnvironment::setResultMsg().

Referenced by MP3ADUTranscoder::getAttributes(), and FramedFilter::getAttributes().

00082                                       {
00083   // Default implementation
00084   envir().setResultMsg("");
00085 }

char const * MediaSource::MIMEtype ( ) const [virtual, inherited]

Reimplemented in RawAMRRTPSource, AC3AudioRTPSource, AMRAudioSource, DVVideoRTPSource, FramedFilter, H261VideoRTPSource, H263plusVideoRTPSource, H264VideoRTPSource, JPEGVideoRTPSource, ADUFromMP3Source, MP3FromADUSource, MP3ADURTPSource, MP3FileSource, MPEG1or2AudioRTPSource, MPEG1or2DemuxedElementaryStream, MPEG1or2VideoRTPSource, MPEG4ESVideoRTPSource, MPEG4GenericRTPSource, MPEG4LATMAudioRTPSource, QuickTimeGenericRTPSource, SimpleRTPSource, and RawQCELPRTPSource.

Definition at line 36 of file MediaSource.cpp.

Referenced by HTTPSink::continuePlaying(), MP3ADUTranscoder::createNew(), MP3FromADUSource::createNew(), ADUFromMP3Source::createNew(), MP3ADUinterleaverBase::getInputSource(), MediaSession::initiateByMediaType(), SimpleRTPSource::MIMEtype(), QuickTimeGenericRTPSource::MIMEtype(), FramedFilter::MIMEtype(), and MPEG1or2DemuxedElementaryStream::MPEG1or2DemuxedElementaryStream().

00036                                         {
00037   return "application/OCTET-STREAM"; // default type
00038 }

Boolean MediaSource::isRTPSource ( ) const [virtual, inherited]

Reimplemented in RTPSource.

Definition at line 43 of file MediaSource.cpp.

References False.

Referenced by RTPSource::lookupByName().

00043                                        {
00044   return False; // default implementation
00045 }

Boolean MediaSource::isMPEG1or2VideoStreamFramer ( ) const [virtual, inherited]

Reimplemented in MPEG1or2VideoStreamFramer.

Definition at line 46 of file MediaSource.cpp.

References False.

Referenced by MPEG1or2VideoRTPSink::sourceIsCompatibleWithUs().

00046                                                        {
00047   return False; // default implementation
00048 }

Boolean MediaSource::isMPEG4VideoStreamFramer ( ) const [virtual, inherited]

Reimplemented in MPEG4VideoStreamFramer.

Definition at line 49 of file MediaSource.cpp.

References False.

Referenced by MPEG4ESVideoRTPSink::sourceIsCompatibleWithUs().

00049                                                     {
00050   return False; // default implementation
00051 }

Boolean MediaSource::isH264VideoStreamFramer ( ) const [virtual, inherited]

Reimplemented in H264VideoStreamFramer.

Definition at line 52 of file MediaSource.cpp.

References False.

Referenced by H264VideoRTPSink::sourceIsCompatibleWithUs().

00052                                                    {
00053   return False; // default implementation
00054 }

Boolean MediaSource::isDVVideoStreamFramer ( ) const [virtual, inherited]

Reimplemented in DVVideoStreamFramer.

Definition at line 55 of file MediaSource.cpp.

References False.

Referenced by DVVideoRTPSink::sourceIsCompatibleWithUs().

00055                                                  {
00056   return False; // default implementation
00057 }

Boolean MediaSource::isJPEGVideoSource ( ) const [virtual, inherited]

Reimplemented in JPEGVideoSource.

Definition at line 58 of file MediaSource.cpp.

References False.

Referenced by JPEGVideoRTPSink::sourceIsCompatibleWithUs().

00058                                              {
00059   return False; // default implementation
00060 }

Boolean MediaSource::isAMRAudioSource ( ) const [virtual, inherited]

Reimplemented in AMRAudioSource.

Definition at line 61 of file MediaSource.cpp.

References False.

Referenced by AMRAudioRTPSink::sourceIsCompatibleWithUs(), and AMRAudioFileSink::sourceIsCompatibleWithUs().

00061                                             {
00062   return False; // default implementation
00063 }

void Medium::close	(	UsageEnvironment &	env,
		char const *	mediumName
	)			`[static, inherited]`

Definition at line 76 of file Media.cpp.

References env, MediaLookupTable::ourMedia(), and MediaLookupTable::remove().

Referenced by afterPlaying(), Medium::close(), closeMediaSinks(), OnDemandServerMediaSubsession::closeStreamSource(), continueAfterTEARDOWN(), WAVAudioFileSource::createNew(), QuickTimeFileSink::createNew(), QCELPAudioRTPSource::createNew(), MP3HTTPSource::createNew(), MP3FileSource::createNew(), AVIFileSink::createNew(), AMRAudioRTPSource::createNew(), WAVAudioFileServerMediaSubsession::createNewStreamSource(), MPEG1or2DemuxedServerMediaSubsession::createNewStreamSource(), MediaSubsession::deInitiate(), MediaSubsession::initiate(), MPEG1or2ProgramStreamFileDuration(), MPEG1or2Demux::noteElementaryStreamDeletion(), ByteStreamMultiFileSource::onSourceClosure1(), StreamState::reclaim(), RTSPServer::removeServerMediaSession(), OnDemandServerMediaSubsession::sdpLines(), H264VideoRTPSink::stopPlaying(), subsessionAfterPlaying(), ClientTrickPlayState::updateStateOnScaleChange(), AMRDeinterleaver::~AMRDeinterleaver(), ByteStreamMultiFileSource::~ByteStreamMultiFileSource(), DarwinInjector::~DarwinInjector(), FramedFilter::~FramedFilter(), H264VideoRTPSink::~H264VideoRTPSink(), InputESSourceRecord::~InputESSourceRecord(), MPEG1or2Demux::~MPEG1or2Demux(), MPEG1or2FileServerDemux::~MPEG1or2FileServerDemux(), MPEG2TransportFileServerMediaSubsession::~MPEG2TransportFileServerMediaSubsession(), MPEG2TransportStreamFromPESSource::~MPEG2TransportStreamFromPESSource(), ServerMediaSession::~ServerMediaSession(), and ServerMediaSubsession::~ServerMediaSubsession().

00076                                                           {
00077   MediaLookupTable::ourMedia(env)->remove(name);
00078 }

void Medium::close ( Medium * medium ) [static, inherited]

Definition at line 80 of file Media.cpp.

References Medium::close(), Medium::envir(), Medium::name(), and NULL.

00080                                  {
00081   if (medium == NULL) return;
00082
00083   close(medium->envir(), medium->name());
00084 }

UsageEnvironment& Medium::envir ( ) const [inline, inherited]

Definition at line 59 of file Media.hh.

References Medium::fEnviron.

00059 {return fEnviron;}

char const* Medium::name ( ) const [inline, inherited]

Definition at line 61 of file Media.hh.

References Medium::fMediumName.

Referenced by QuickTimeFileSink::addAtom_hdlr2(), Medium::close(), MP3ADUTranscoder::createNew(), MP3FromADUSource::createNew(), ADUFromMP3Source::createNew(), and MP3FileSource::initializeStream().

00061 {return fMediumName;}

Boolean Medium::isSink ( ) const [virtual, inherited]

Reimplemented in MediaSink.

Definition at line 90 of file Media.cpp.

References False.

Referenced by MediaSink::lookupByName().

00090                              {
00091   return False; // default implementation
00092 }

Boolean Medium::isRTCPInstance ( ) const [virtual, inherited]

Reimplemented in RTCPInstance.

Definition at line 94 of file Media.cpp.

References False.

Referenced by RTCPInstance::lookupByName().

00094                                      {
00095   return False; // default implementation
00096 }

Boolean Medium::isRTSPClient ( ) const [virtual, inherited]

Reimplemented in RTSPClient.

Definition at line 98 of file Media.cpp.

References False.

Referenced by RTSPClient::lookupByName().

00098                                    {
00099   return False; // default implementation
00100 }

Boolean Medium::isRTSPServer ( ) const [virtual, inherited]

Reimplemented in RTSPServer.

Definition at line 102 of file Media.cpp.

References False.

Referenced by RTSPServer::lookupByName().

00102                                    {
00103   return False; // default implementation
00104 }

Boolean Medium::isMediaSession ( ) const [virtual, inherited]

Reimplemented in MediaSession.

Definition at line 106 of file Media.cpp.

References False.

Referenced by MediaSession::lookupByName().

00106                                      {
00107   return False; // default implementation
00108 }

Boolean Medium::isServerMediaSession ( ) const [virtual, inherited]

Reimplemented in ServerMediaSession.

Definition at line 110 of file Media.cpp.

References False.

Referenced by ServerMediaSession::lookupByName().

00110                                            {
00111   return False; // default implementation
00112 }

Boolean Medium::isDarwinInjector ( ) const [virtual, inherited]

Reimplemented in DarwinInjector.

Definition at line 114 of file Media.cpp.

References False.

Referenced by DarwinInjector::lookupByName().

00114                                        {
00115   return False; // default implementation
00116 }

TaskToken& Medium::nextTask ( ) [inline, protected, inherited]

DeviceParameters DeviceSource::fParams [private]

Definition at line 50 of file DeviceSource.hh.

unsigned char* FramedSource::fTo [protected, inherited]

Definition at line 74 of file FramedSource.hh.

unsigned FramedSource::fMaxSize [protected, inherited]

Definition at line 75 of file FramedSource.hh.

unsigned FramedSource::fFrameSize [protected, inherited]

Definition at line 76 of file FramedSource.hh.

Referenced by FramedSource::afterGetting(), ByteStreamMultiFileSource::afterGettingFrame(), EndianSwap16::afterGettingFrame1(), HostFromNetworkOrder16::afterGettingFrame1(), NetworkFromHostOrder16::afterGettingFrame1(), PCMFromuLawAudioSource::afterGettingFrame1(), uLawFromPCMAudioSource::afterGettingFrame1(), MPEG2TransportStreamFramer::afterGettingFrame1(), MPEG1or2DemuxedElementaryStream::afterGettingFrame1(), MP3ADUTranscoder::afterGettingFrame1(), MPEG2TransportStreamTrickModeFilter::attemptDeliveryToClient(), MPEGVideoStreamFramer::continueReadProcessing(), MPEG1or2AudioStreamFramer::continueReadProcessing(), H263plusVideoStreamFramer::continueReadProcessing(), MPEG2TransportStreamMultiplexor::deliverDataToClient(), MPEG2IFrameIndexFromTransportStream::deliverIndexRecord(), WAVAudioFileSource::doGetNextFrame(), QCELPDeinterleaver::doGetNextFrame(), MultiFramedRTPSource::doGetNextFrame(), MPEG2TransportStreamTrickModeFilter::doGetNextFrame(), MPEG2TransportStreamFramer::doGetNextFrame(), H264FUAFragmenter::doGetNextFrame(), DVVideoStreamFramer::doGetNextFrame(), AMRDeinterleaver::doGetNextFrame(), AMRAudioFileSource::doGetNextFrame(), ADTSAudioFileSource::doGetNextFrame(), MultiFramedRTPSource::doGetNextFrame1(), MP3FileSource::doGetNextFrame1(), ADUFromMP3Source::doGetNextFrame1(), ByteStreamFileSource::doReadFromFile(), MP3FromADUSource::generateFrameFromHeadADU(), DVVideoStreamFramer::getAndDeliverData(), BasicUDPSource::incomingPacketHandler1(), AC3AudioStreamFramer::parseNextFrame(), MP3ADUdeinterleaver::releaseOutgoingFrame(), and MP3ADUinterleaver::releaseOutgoingFrame().

unsigned FramedSource::fNumTruncatedBytes [protected, inherited]

Definition at line 77 of file FramedSource.hh.

Referenced by FramedSource::afterGetting(), ByteStreamMultiFileSource::afterGettingFrame(), EndianSwap16::afterGettingFrame1(), HostFromNetworkOrder16::afterGettingFrame1(), NetworkFromHostOrder16::afterGettingFrame1(), PCMFromuLawAudioSource::afterGettingFrame1(), uLawFromPCMAudioSource::afterGettingFrame1(), MPEG1or2DemuxedElementaryStream::afterGettingFrame1(), MP3ADUTranscoder::afterGettingFrame1(), MPEGVideoStreamFramer::continueReadProcessing(), MPEG1or2AudioStreamFramer::continueReadProcessing(), MPEG2TransportStreamMultiplexor::deliverDataToClient(), QCELPDeinterleaver::doGetNextFrame(), H264FUAFragmenter::doGetNextFrame(), DVVideoStreamFramer::doGetNextFrame(), AMRDeinterleaver::doGetNextFrame(), AMRAudioFileSource::doGetNextFrame(), ADTSAudioFileSource::doGetNextFrame(), MultiFramedRTPSource::doGetNextFrame1(), FramedSource::getNextFrame(), AC3AudioStreamFramer::parseNextFrame(), MP3ADUdeinterleaver::releaseOutgoingFrame(), and MP3ADUinterleaver::releaseOutgoingFrame().

struct timeval FramedSource::fPresentationTime [read, protected, inherited]

Definition at line 78 of file FramedSource.hh.

unsigned FramedSource::fDurationInMicroseconds [protected, inherited]

Definition at line 79 of file FramedSource.hh.


Public Types
typedef void(	afterGettingFunc )(void *clientData, unsigned frameSize, unsigned numTruncatedBytes, struct timeval presentationTime, unsigned durationInMicroseconds)
typedef void(	onCloseFunc )(void *clientData)
Public Member Functions
void	getNextFrame (unsigned char to, unsigned maxSize, afterGettingFunc afterGettingFunc, void afterGettingClientData, onCloseFunc onCloseFunc, void *onCloseClientData)
void	stopGettingFrames ()
virtual unsigned	maxFrameSize () const
Boolean	isCurrentlyAwaitingData () const
virtual void	getAttributes () const
virtual char const *	MIMEtype () const
virtual Boolean	isRTPSource () const
virtual Boolean	isMPEG1or2VideoStreamFramer () const
virtual Boolean	isMPEG4VideoStreamFramer () const
virtual Boolean	isH264VideoStreamFramer () const
virtual Boolean	isDVVideoStreamFramer () const
virtual Boolean	isJPEGVideoSource () const
virtual Boolean	isAMRAudioSource () const
UsageEnvironment &	envir () const
char const *	name () const
virtual Boolean	isSink () const
virtual Boolean	isRTCPInstance () const
virtual Boolean	isRTSPClient () const
virtual Boolean	isRTSPServer () const
virtual Boolean	isMediaSession () const
virtual Boolean	isServerMediaSession () const
virtual Boolean	isDarwinInjector () const
Static Public Member Functions
static DeviceSource *	createNew (UsageEnvironment &env, DeviceParameters params)
static Boolean	lookupByName (UsageEnvironment &env, char const sourceName, FramedSource &resultSource)
static Boolean	lookupByName (UsageEnvironment &env, char const sourceName, MediaSource &resultSource)
static Boolean	lookupByName (UsageEnvironment &env, char const mediumName, Medium &resultMedium)
static void	handleClosure (void *clientData)
static void	close (UsageEnvironment &env, char const *mediumName)
static void	close (Medium *medium)
Protected Member Functions
	DeviceSource (UsageEnvironment &env, DeviceParameters params)
virtual	~DeviceSource ()
virtual void	doStopGettingFrames ()
TaskToken &	nextTask ()
Static Protected Member Functions
static void	afterGetting (FramedSource *source)
Protected Attributes
unsigned char *	fTo
unsigned	fMaxSize
unsigned	fFrameSize
unsigned	fNumTruncatedBytes
timeval	fPresentationTime
unsigned	fDurationInMicroseconds
Private Member Functions
virtual void	doGetNextFrame ()
void	deliverFrame ()
Private Attributes
DeviceParameters	fParams

DeviceSource Class Reference

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Private Member Functions

Private Attributes

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Field Documentation
